On-Floor, Ligature Resistant Bariatric Stainless Steel Toilet for Front Mount
Model WH2125-A Series
Installation Instructions
Install Guide WH2125-A-2-FM Toilet (español pdf)
Submittal
Submittal WH2125-A Series Toilet (español pdf)
Model WH2125-A Series
On-Floor, Ligature Resistant Bariatric Stainless Steel Toilet for Front Mount
14 gage 304 stainless steel on-floor toilet capable bearing loads of up to 5,000 lbs; toilet requires 25 psi (172 kpa) water supply and operate with as little as 1.28 GPF (4.85 LPF); Specify -FM (front wall mount) or -RM (rear mount/chase/mounting from behind wall)
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | On-Floor, ADA Compliant Bariatric Stainless Steel Toilet - Front Mount, On-Floor, Wall Waste [WH2125-A-T-2-FM | Top Supply; WH2125-A-W-2-FM | Wall Supply] | 0 | 552 KB | ||
| | On-Floor, Ligature-Resistant Bariatric Stainless Steel Toilet [WH2125-A-T-2-FM | Top Supply, Wall Waste, Front Mount; WH2125-A-W-2-FM | Wall Supply, Wall Waste, Front Mount; WH2125-A-T-3-FM | Top Supply, Floor Waste, Front Mount; WH2125-A-W-3-FM | Wall Supply, Floor Waste, Front Mount; WH2125-A-T-2-RM | Top Supply, Wall Waste, Rear/Chase Mount; WH2125-A-W-2-RM | Wall Supply, Wall Waste, Rear/Chase Mount; WH2125-A-T-3-RM | Top Supply, Floor Waste, Rear/Chase Mount; WH2125-A-W-3-RM | Wall Supply, Floor Waste, Rear/Chase Mount] | 0 | 605 KB | ||
| | On-Floor, Ligature Resistant Bariatric Stainless Steel Toilet | 0 | 671 KB | ||
| | Who we are, Our History, Morris Group International Today | 0 | 21 MB | ||
| | On-Floor, ADA Compliant Bariatric Stainless Steel Toilet - Rear (Chase) Mount, On-Floor, Wall Waste includes Top & Wall Supply Configuration | 0 | 236 KB | ||
| | On-Floor, ADA Compliant Bariatric Stainless Steel Toilet - Front Mount, On-Floor, Floor Waste includes Top & Wall Supply Configuration | 0 | 158 KB | ||
| | On-Floor, ADA Compliant Bariatric Stainless Steel Toilet - Rear (Chase) Mount, On-Floor, Floor Waste includes Top & Wall Supply Configuration | 0 | 240 KB |
Specifications
| Brand | Acorn Engineering Co., Whitehall |
| Mount | On-Floor, Against Wall, Front Mount, Rear Mount (Chase), Surface Mount |
| Material | Stainless Steel |
| Compliance | ASME A112.19.3-2008, CSA B45.4-2008, ADA |
| Additional Benefits | Contains Recycled Material, Recyclable, Water Saving, Bariatric Use |
